Yamaha NS-IW280C White Natural Sound 3-way In-ceiling Speaker System (Pair)
Yamaha NS-IW280C White Natural Sound 3-way In-ceiling Speaker System (Pair)
Yamaha NS-IW280C White Natural Sound 3-way In-ceiling Speaker System (Pair)

Yamaha

Yamaha NS-IW280C White Natural Sound 3-way In-ceiling Speaker System (Pair)

$158.27

NS-IW280CWH

Hurry, only 2 items left in stock!

Pairs well with

See Innovation in Action

Watch as advanced features, intuitive design, and exceptional performance come together in real time.

Experience Innovation, Performance & Style in Every Detail.

Product Details


Bring Yamaha’s celebrated Natural Sound to your ceiling. The NS‑IW280CWH is a discreet, audiophile‑minded 3‑way in‑ceiling speaker pair that blends wide, room‑filling coverage with precise imaging. A tilting 6.5″ polypropylene mica‑filled woofer projects mid‑bass energy toward the listening area, while dual 0.75″ swivel dome tweeters (“Sound Max”) extend airy, detailed highs up to 28 kHz. With an installation‑friendly design, paintable aluminum grilles, and robust binding‑post terminals, the NS‑IW280CWH integrates cleanly into modern interiors while delivering the smooth, low‑fatigue sound Yamaha is known for.

Featured Callouts

  • Tilt + Swivel Array: Aimable woofer and dual swivel tweeters to focus clarity where you sit.
  • Broad Soundstage: Dual‑tweeter 3‑way topology for wide, even high‑frequency coverage.
  • Décor‑Ready: Low‑profile, paintable aluminum grilles with included paint mask.
  • Installer‑Friendly: Cutout template, protective covers, and secure binding‑post connections.

Key Features

  • Handles up to 30 W RMS / 100 W peak.
  • 6.5″ polypropylene, mica‑filled woofer in a tilted mounting for aimable mid‑bass.
  • Two 0.75″ dome tweeters on swivels (“Sound Max”) for precise high‑frequency placement.
  • Dual‑tweeter design creates a broad, cohesive soundstage across large listening areas.
  • Paintable aluminum grille with included protective cover to match any room.

Features

  • 3‑way in‑ceiling architecture for smooth handoff from lows to highs.
  • Swivel tweeters & tilting woofer let you fine‑tune imaging after installation.
  • Wideband response from 65 Hz to 28 kHz for full, detailed reproduction.
  • Durable construction with aluminum grille and secure mounting system.
  • Ready to finish: paint mask, glue strips, and cutout template included for a clean fit.

Included In The Box

  • Yamaha NS‑IW280CWH In‑Ceiling Speakers (Pair)
  • 2 × Paintable Speaker Grilles
  • Cutout Template
  • Paint Protective Cover
  • 2 × Glue Strips
  • Limited 2‑Year Manufacturer Warranty

Technical Specifications

System Type In‑ceiling, 3‑way, passive
Drivers LF: 6.5″ (165 mm) polypropylene, mica‑filled woofer (tilting)
HF: 2 × 0.75″ (19 mm) dome tweeters (swiveling)
Frequency Response 65 Hz – 28 kHz
Sensitivity 85 dB (2.83 V / 1 m)
Impedance 8 Ω nominal
Power Handling 30 W RMS / 100 W peak
Crossover Frequencies 6 kHz, 9 kHz
Inputs 1 × Binding‑post pair
Color White (paintable grille)
Mounting In‑ceiling
Overall Dimensions (Ø × D) 10.3″ × 5.0″ (262 × 127 mm)
Cutout Diameter 9.8″ (250 mm)
Mounting / Cutout Depth 4.8″ (122 mm)
Construction Aluminum grille; rigid baffle assembly
Unit Weight 3.3 lb (1.5 kg) each
Environmental Resistance Not rated for outdoor / high‑moisture use
Warranty Limited 2‑Year Manufacturer Warranty
Package Weight 8.35 lb
Box Dimensions (L × W × H) 13.622″ × 12.126″ × 11.417″
